Bike Craze Electric Bikes (Sales and Service)
1171 N. Kraemer Blvd - Anaheim, Ca 92806
714 744-0266
WEBSITE: bikecraze.com
Store Hours: Mon - 11-4, Tue-Fri - 10-5, Sat - 9-5, Sun Occasionally, Call First
THE COOL BIKE STORE! - IN BUSINESS FOR OVER 20 YEARS!
Authorized Dealer - Full Warranty- Full Service and Custom Builds! Over 50 Brands to choose!
Electric Bikes - BMX Bikes - Folding Bikes - Skateboards - Car Racks - Helmets - Locks available in store.
Over 100 Bikes built on our Show floor ready for a test ride!
• Classes: Class 3(Ebikes can go up to 28mph with pedal assistance) Speed: Up to 28 MPH on Pedal Assist; 20 MPH on Throttle; Range: Up to 90 Miles* on PAS, 30 Miles* on Throttle(*Range Per Charge is measured under the conditions that power is sufficient, with a 75kg load, at 86°F(30°C), 70% humidity, on a level road, in pedal assist mode with level 1 assistance, and in pure electric riding mode by throttle. Actual results may vary based on differences in temperature, load, wind speed, road conditions and other factors.)
• Frame: 6061 Alluminum Alloy with Internal Battery Fork: Hydraulic Suspension Fork with 60mm travel, with lockout
• Rim: Aluminum 26" 36H Front & Rear Spokes: Black Stainless, Front 13Gx 244/246mm, Rear 12Gx217/219mm Hubs: Disc Nutted Front Axles Tires: Kenda 26" x 4.0" Fat Tires Tubes: Butyl Rubber, Schrader Valve
• Motor: 750W (Peak 1000W),85Nm Throttle: Throttle on demand - Throttle from a complete stop Display: TFT Smart Easy Read Display with Backlight, Colorful screen Battery: Removable Internal Lithium-ion Battery 48V15AH (720Wh) with LG cells Pedal Assist: 5 Levels Sensors: Torque Sensor Charger: 48V 2 Amp Charger, Approx. 8 Hour Charging Light: Front 48V LED Light 75 LUX Tail Light: Rear Break Light, 12V 20 LUX
• Crankset: 170mm w/ 52 T Rear Derailleur: Shimano ARDTY500D 7-Speed Freewheel: Shimano 14-28T, 7-Speed freewheel Shift Lever: Shimano 7-Speed RevoShift Chain: KMC 124 Link, 7-Speed Pedals: Alloy Platform
• Saddle: Comfortable Wide Saddle Seatpost: Forged Alloy, Ø30.4*350mm Seat Clamp: Ø35 mm Quick Release Stem: Bar bore: Ø31.8mm, Clamp I.D.: Ø28.6mm, HEIGHT: 40mm, RISE:±7° Handlebars: Aluminum Ø31.8mm, Width 720mm Headset: Sealed Bearing Headset Grips: Ergonomic Comfort Brakes: Hydraulic Disc Brakes w/180mm discs, w/ power-cut-off function Kickstand: Alloy, Rear Mount Fenders: Plastic 26"x110mm Rear Rack: Aluminum alloy rear rack
• Product Weight: 35.5KG (78.26LBS) (including battery) Package Weight: 43.6KG (96.12LBS) Battery Weight: 4KG (8.82LBS) Max Load Capacity: 300 lbs Payload Capacity
• Product Size: 1930*740*1210MM Package Size: 1590*325*895MM
Warranty: 2 Year
