Used Snowhill Eng. 6' x 12' CNC Plasma Table w/ HyperTherm ProMax 200 - $12,900 (San Marcos, CA)
QR Code Link to This Post
Table Size: 6' x 12'
CNC Computer Control w/ Software
Equipped with HyperTherm MaxPro 200 Power Source
HyperTherm MaxPro 200 Specifications:
Input voltages 200/208 VAC, 3-PH, 50 Hz, 108/104 A
220 VAC, 3-PH, 50 – 60 Hz, 98 A
240 VAC, 3-PH, 60 Hz, 90 A
380 VAC, 3-PH, 50 Hz, 57 A
400 VAC, CE, 3-PH, 50 – 60 Hz, 54 A
415 VAC, CE, 3-PH, 50 Hz, 52 A
440 VAC, 3-PH, 50 – 60 Hz, 49 A
480 VAC, 3-PH, 60 Hz, 45 A
600 VAC, 3-PH, 60 Hz, 36 A
Output voltage 50 – 165 VDC
Maximum output current 200 A
Duty cycle rating 100% @ 33 kW, at 40° C (104° F)
Operating temperature -10° C to 40° C (+14° F to +104° F)
Power factor 0.98 @ 33 kW output
Maximum OCV 360 VDC
Dimensions 102 cm (40.14") H, 69 cm (27.12") W,
105 cm (41.23") L
Weight 335 kg (740 lbs)
Gas supply
Plasma gas
Shield gas
Supply gas pressure
Air, O2, N2
Air, N2
6.2 +/- 0.7 bar (90 +/- 10 psig)
Virtually dross-free cutting capacity - mild steel 20 mm (3/4")
Production pierce capacity - mild steel 32 mm (1 1/4")
Severance* - mild steel 75 mm (3")
Bevel - 200 amp consumables support 45° bevel capability
Machine is in Good Working Condition. In Plant, Under Power. Demos Available upon Request. Youtube Link to Video of machine running is below:
https://youtube.com/shorts/D2hv5aVzGco?si=cYFYsFvXc7jcolPm
Customer purchased a new, larger capacity SengFeng Fiber Laser and won't need the Used Snowhill plasma anymore so they would like to sell it.
Available for Immediate Delivery!
Buyer is Responsible for Freight & Rigging
Price: $12,900.00 or Best Offer
FOB(Location): San Marcos, CA 92078
Please provide a contact email or telephone # in your reply to this ad if you would like to purchase, schedule demo, etc. Thank you.
***Machine is Sold "As-Is, Where-Is" with No Warranty Expressed or Implied. Buyer is Responsible for Machine Inspection prior to Shipment.
